| Features:
1. Dual Beam Light Path
Less circuit fluctuation and stray light, higher stability.
2. Powerful Stand-alone Operation System
Spectrum scanning, Standard curve, Kinetics, Multi wavelength, DNA/Protein test can be operated directly on device without PC software.
3. Unique Long Light Path Design
520mm long light path greatly improved the wavelength resolution.
4. Rigid Structure, 16mm-thick Optical Base
All optical components are fixed on a 16mm thick rigid die-cast aluminum board to promise higher stability and reliability.
5. One-button Automatic Calibration System
One button auto calibration for baseline, wavelength and dark current to keep device in a good condition.
6. 6 inches High-Definition Large LCD Display
Large LCD display, all data and graphs can be shown directly and clearly.
7. Easy Data Output by USB/Parallel Port
USB Port: Connect to computer and operate through PC software. ( PC software is standard.)
Parallel Port: Connect to Micro Thermo printer to print test data. ( Micro Printer is optional.)
8. Powerful Software Functions
Spectrum scanning, Standard curves, Kinetics, Multi wavelength scanning, DNA/Protein test can be operated directly on computer.
Specifications:
Model |
UV-9000 |
UV-9000A |
UV-9000S |
Optical System |
Double Beam (1200 Lines/mm Grating) |
Wavelength Range |
190-1100nm |
Bandwidth |
1.8nm |
1nm |
0.5/1/2/4 nm |
Wavelength Accuracy |
±0.1nm at D2 656.1nm, ±0.3nm at allrange |
Wavelength Repeatability |
0.1nm |
Photometric Accuracy |
±0.2%T(0-100%T) |
Photometric Repeatability |
≤0.1%T(0-100%T) |
Photometric Range |
-0.3-3A, 0-200%T, 0-9999C |
Stability |
≤0.0005A/h at 250nm, 500nm |
Stray Light |
≤0.03%Tat 220nm, 360nm |
Output |
USBport & Parallel Port |
Display |
320*240 Dots LCD |
Light Source |
W Lamp & D2Lamp |
Power Requirements |
AC110/220V, 50/60Hz |
|
Standard Accessories:
Item |
Description |
Quantity |
Unit |
1 |
Spectrophotometer |
1 |
unit |
2 |
PC software |
1 |
set |
3 |
1cm Glass cuvette |
4 |
pcs |
4 |
1cm Quartz cuvette |
2 |
pcs |
5 |
Power cord |
1 |
pcs |
6 |
User’s manual |
1 |
pcs |
7 |
Dust cover |
1 |
pcs |
|
