| Applications:
Meet the inspection and diagnosis of primary hospitals in abdomen, obstetrics, gynecology, urinary system, small organs, superficial, vascular, pediatrics, neonatal, muscle, physical examination and other aspects.
Specifications:
- Operating system: Windows 10
- Spectral Pulse Doppler (PW)
- Directional Energy Doppler
- Real-time triple synchronization
- Spatial composite imaging
- Tissue harmonic imaging
- 2B/4B imaging mode
- System language supports: Chinese, English, French, Russian and Spanish, five languages
3.9 Monitor: ≥15 inches
- Integrated clipboard: display the saved images at the bottom of the screen, which can be directly transferred or deleted
- The system has the function of field upgrade
- Preset conditions: For different inspections, preset the inspection conditions to optimize the image, reduce the adjustment during operation, and commonly required external adjustment and combined adjustment
- Probe interface ≥ 1
- With trapezoidal imaging function
- With one-click intelligent optimization
Probes:
Convex probe:
frequency 2.0MHz, 2.5MHz, 3.0MHz, 3.5MHz, 4.0MHz, 5.5MHz, H4.0MHz, H5.0MHz, eight-segment frequency conversion (depth 30-255mm)
Linear probe:
Frequency: 6.0MHz, 7.5MHz, 8.5MHz, 10.0MHz, 12.0MHz, H10.0MHz, six-segment frequency conversion (depth 20-128mm)
Trans-vaginal probe:
Frequency: 4.5MHz, 5.0MHz, 6.0MHz, 6.5MHz, 7.0MHz, 9.0MHz, H8.0MHz, seven-segment frequency conversion (depth 30-156mm)
Micro-convex probe (R15):
frequency 4.5MHz, 5.0MHz, 6.0MHz, 6.5MHz, 7.0MHz, 9.0MHz, H8.0Mhz, seven-segment frequency conversion (depth 30-111mm)
Rectal probe:
frequency 4.0MHz, 6.5MHz, 9.0MHz, H8.0Mhz, four-segment frequency conversion (depth 20-110mm)
Phased array probe:
frequency 2.0MHz, 2.5MHz, 3.0MHz, 3.5MHz, 4.0MHz, 5.0MHz, H3.0MHz, H4.0MHz, eight-segment frequency conversion (depth 100-244mm)

  |
|
