| Applications:
To meet the inspection and diagnosis of primary hospitals in abdominal, obstetrics, gynecology, heart, urinary system, small organs, superficial, vascular, pediatrics, neonatal, muscle, physical examination and other aspects.
Specifications:
- Ultrasound host operating system: Windows 10 operating system
- Spectral Pulse Doppler
- Directional Energy Doppler
- Real-time triple synchronization
- With space composite imaging
- Possess tissue harmonic imaging technology
- 2B/4B imaging mode
- System language: Chinese, English, French, Russian and Spanish five languages
- Monitor: 21.5 inches
- Integrated clipboard: display the saved image on the right side of the screen, which can be directly transferred or deleted
- The system has the function of field upgrade
- Preset conditions: for different inspections, preset the inspection conditions to optimize the image, reduce the adjustment during operation, and commonly required external adjustment and combined adjustment
- Probe interface 3
- With trapezoidal imaging function
- With one-click intelligent optimization
Probes:
Convex probe:
Frequency2.0MHz/2.5MHz/3.0MHz/3.5MHz/4.0MHz/5.5MHz/H4.0MHz/H5.0MHz, eight-segment frequency conversion (depth 30-255MM)
Linear array probe:
Frequency:6.0MHz/7.5MHz/8.5MHz/10.0MHz/12.0MHz/H10.0MHz, six-segment frequency conversion (depth 20-128MM)
Transvaginal probe:
Frequency:4.5MHz/5.0MHz/6.0MHz/6.5MHz/7.0MHz/9.0MHz/H8.0MHz, seven-segment frequency conversion (depth 30-156MM)
Micro-convex probe (R15):
frequency4.5MHz/5.0MHz/6.0MHz/6.5MHz/7.0MHz/9.0MHz/H8.0Mhz, seven-segment frequency conversion (depth 30-111MM)
Rectal probe:
frequency4.0MHz/6.5MHz/9.0MHz/H8.0Mhz,
four-segment frequency conversion (depth 20-110MM)
Phased array probe：2.0MHz/2.5MHz/3.0MHz/3.5MHz/4.0MHz/5.0MHz/H3.0MHz/H4.0MHz，eight-segment frequency conversion（depth100-244MM）

  |
|
