1. Usage
FD-800C/D ultrasonic fetal doppler meets the fetus daily check and routine examination at clinic, community and hospital

2. Features
-  Easy and convenient operation
-  High-fidelity, crystal clear sound
-  Earphone and speaker are feasible
-  High sensitivity water-proof probe
-  Display with backlight LCD and colour LCD
-  Unique ergonomic design
-  USB functions to transmit data
-  Flexible menu and parameter function
-  Both audio and light alarm
-  Multiple working modes
-  Colour LCD with touch and automatic storage function and play back of FHR curve

3. Technical Specification
-  Ultrasound frequency: 2MHz
-  Ultrasound intensity: <10mW/cm2
-  Power supply:  Rechargeable battery
               AC 220/110V, 50/60Hz
-  Display: 65mm×50mm LCD
-  FHR Measuring range: 50~230bpm
-  FHR resolution: 1bpm
-  FHR accuracy: ±2bpm
-  Power consumption: <12W
-  Dimension :220mm ×220mm ×140mm
-  Gross weight:2.1kg
-  Printing paper size: 50mm

4. Configuration
-  Main body
-  Ni-MH battery
-  2MHz probe
-  Adaptor

5. Option
-  Earphone
-  PC software
-  Carry case
-  Trolley
-  3MHz probe
-  Printing system

6. FD-800 Series Difference Table

	Download Literature:
	FD-800 Desktop Fetal Doppler
